MAJOR COMPONENTS AND CONSTRUCTION

KAUDY Plate Heat Exchanger consist of a plate pack of a calculated of embossed plates with perimeter gaskets clamped securely between two thick carbon steel plates by means of tie rods. The plate have opening at corners to direct process and service KAUDY flows through the passageways between plate, KAUDY Flow Alternately between every other plate in order to achive hign efficiency heat transfer. The thin fluid flow and the hign turbulance creates by “KAUDY” proprietary embossed plate patterns produce low pressure drops and hign heat transfer coefficients

  • Carbon Steel
  • Stainless Steel



KAUDY PLATE HEAT EXCHANGER FRAME



KAUDY PLATE HEAT EXCHANGER GASKET MATERIAL AVAILABLE

  • Nitrile Rubber (NBR)
  • Ethylene Propylene Rubber (EPDM)
  • Viton G (FKMG)
  • Neoprene (Chloroprene)
  • Hypalon (CSM)
  • Other material available or request



KAUDY PLATE HEAT EXCHANGER PLATE MATERIAL AVAILABLE

  • AISI 304
  • AISI 316
  • AISI 316l
  • A VESTA SMO254
  • C-2000
  • NICKEL
  • Ti
